A modular furniture concept with proposed shared components. Concept only; design and compatibility require factory validation.
Front, image 1 of 5
Five views from one proposed CAD model. Materials, dimensions and manufacture remain unvalidated.
Entry bench
Concept design — manufacturing specifications and pricing pending. Purchases are disabled.
Request a quote by email ↗
Opens your email app. Pricing and manufacture will need confirmation.
Proposed components
Recipe P-765DBC1B69ADFFA54B606D07. Design quantities shown where defined; engineering, connectors, hardware and fit remain unvalidated. This is not a fabrication-ready bill of materials or a statement of inventory availability.
- cad-part-1 × 2 each — Portal bench end frame — 400 × 420 mm concept · MF-PART-PORTAL-END400X420-R01-OAK
- cad-part-2 × 1 each — Portal connecting rail — 900 mm concept · MF-PART-PORTAL-RAIL900-R02-OAK
- cad-part-3 × 2 each — Portal connector — 82 mm concept · MF-PART-PORTAL-CONNECTOR82-R01-OAK
- cad-part-4 × 1 each — Portal bench seat — 1100 × 430 × 30 mm concept · MF-PART-PORTAL-SEAT1100X430X30-R01-OAK
- cad-part-5 × 1 each — Square shelf · MF-SHELF-Q-R01-MAT01-FIN01
- cad-part-6 × 1 each — Portal lower-shelf cradle — 902 mm concept · MF-PART-PORTAL-SHELF-CRADLE902-R01
Render derived from parametric concept model B02-LEGACY-FIT-LAYOUT-20261101-01. Proposed dimensions, joinery and manufacture require maker approval.
Notes from this concept model
Entry bench. Concept design — manufacturing specifications and pricing pending. Proposed CAD envelope 1100 × 430 × 450 mm; manufacturing dimensions remain unvalidated. Length × width × height; sold unit each. This layout reuses the exact separately listed component concepts in its proposed recipe. Hardware, joining, compatibility, material supply and any applicable performance/compliance requirements remain unvalidated.
Explore the 3D concept
Static CAD-derived concept image. Load 3D when ready.
- Proposed length × width × height
- 1100 × 430 × 450 mm
- Model revision
- B02-LEGACY-F…
- Design status
- Concept; material supply, joinery, tolerances and manufacturing approval pending.
